Double channel 1/8 fold napkin paper folding machine

Double channel 1/8 fold vacuum type napkin paper folding machine

双层餐巾纸3

双排餐巾纸

双排餐巾纸1-8

双排餐巾纸2

Model	SAN-NT-380D
Folding type	1/8 fold
Raw material width	380 ±20 mm （200-400 mm available）
Raw material max diameter	1100mm
Products size	190*95±20mm (can be ordered )
Power	Frequency conversion speed regulator
Transmission system	Gear and chains
Embossing unit	Steel to wool rollers with heating device(Others to be ordered)
Capacity	500-600 sheets/min
Counting	Electronic counting
Paper loading	Pneumatic loading
Power	12 kw
Power supply	380V 50HZ
Dimension	450015001800 mm
Weight	2000kg
